Vacuum Permanent-Magnetic Filter

The machine is a top-feeding, drum-like, outside-filtering vacuum permanent-magnetic filter, suitable for dewatering of coarse and strong-magnetic particles. Inside the drum is a strontium ferrite permanent-magnetic, which enables the magnetic particles t

Purchase Hotline  400-1122-958

|/PRODUCT DETAIL

Product introduction:

The machine is a top-feeding, drum-like, outside-filtering vacuum permanent-magnetic filter, suitable for dewatering of coarse and strong-magnetic particles. Inside the drum is a strontium ferrite permanent-magnetic, which enables the magnetic particles to be absorbed on the filter cloth quickly. The magnetic filter is mainly for dewatering of ore pulp containing coarse and strong magnetic particles. Due to the top feeding design, particles are obviously stratified in the filter cake according to their grain sizes. When the magnetic concentrate is shaped into filter cakes, the coarse particles move faster than the fine particles toward the filter cloth under the effect of gravity and magnetic force. The coarse particles touch the filter cloth first, making the filter cake breathable. When attracted by the magnetic force, the magnetic particles in the ore pulp are laid out on the surface of the drum radially and give rise to magnetic stirring due to magnetic pole variation. All these features create a favorable environment for filter cake dewatering; filter cakes produced in this way are usually thick and have good breathability, and improved productivity which is three times more than that of other drum vacuum filters of the same specifications.

The specific susceptibility of solid particles in ore pulp of the machine is at least 3OOO×10-6 cm/gram, and the granularity is between 015mm and 0.8mm.



The image:








|/VIDEO PRODUCT

|/TECHNICAL PARAMETER


Model

GYW-3

GYW-5

GYW-8

GYW-12

GYW-20

Filter area(㎡)

3

5

8

12

20

Cylinder

Diameter(mm)

1600

2000

2250

Length(mm)

700

900

1400

2000

2650

Speed(r/min)

0.5~2.0

vacuity required (kpa)

60~80

sucking rate (m3/min.㎡)

0.5~2.0

blast pressure   required (kpa)

10~30

blast volume (m3/min.㎡)

0.1~0.5

Magnetic intensity on the roller surface

 (mT)

82

87

ore   concentration %

≥60

maximum   production capacity (t/h)

6~9

14~18

22~43

33~65

54~108

filter cake moisture%

8~11

8~10

Size(mm)

1895*2506*2087

2110*2755*2500

2610*2905*2500

3210*2905*2500


Weight(t)

3.27

3.94

4.76

5.42

6.5

Motor

type

Y100L-6

Y112M-6

Y132M1-6

Power(kw)

1.5

2.2

4

Speed(r/min)

940

960
